Rated Voltage: DC 12V
Operating Voltage: 9V~16V
Current Consumption: ≤80mA(12v)
Reactive Time: ≤600ms(12v)
1. PIN1+, PIN4-: The switch will be disconnected in locking status
2. PIN1-, PIN4+: The switch will be connected in locking status
Attention:
1: The Thermistor is placed beside L1
2: The Thermistor is NTC
3: (Specification: T=25℃ Resistance=10±1% KΩ)
4: The resistance decrease with increasing temperature locking status
KC
CE
ENEC
ROHS
UL
TUV
The Thermistor is placed beside L1
The Thermistor is NTC
(Specification: T=25℃ Resistance=10±1% KΩ)
The resistance decrease with increasing temperature locking status
| Rated Voltage | DC 12V |
| Operating Voltage | 9V~16V |
| Current Consumption | ≤80mA(12v) |
| Reactive Time | ≤600ms(12v) |
| PIN1+, PIN4- | The switch will be disconnected in locking status |
| PIN1-, PIN4+ | The switch will be connected in locking status |
